Archimedean Screw hydro turbines turning the screw on CO2
Romney Weir is turning the screw on CO2
Romney weir is turning the screw on CO2. Two Archimedean Screw hydro turbines, rated at 150kW each
and designed by Mann Power Consulting Ltd., are to be installed on the weir to generate clean, green electricity that will be used locally. With a total capacity of 300kW this will be one of the largest Archimedean Screw hydro schemes installed to date in the UK and Ireland. The largest single Archimedes screw was recently installed at Shane’s Castle in Northern Ireland, rated at 214kW it is the largest ever manufactured Archimedean Screw hydro generator and was designed and supplied by Mann Power .
Romney Weir ‘A’ is in Windsor. The weir was built in the 1960s and is used to control water levels between Old Windsor lock and Boveney lock. The Romney Weir hydro scheme will utilise just two of the ten existing weir bays and have little effect on current weir operations. Weirs were originally built to control water levels for navigation and flood risk purposes but can now take advantage of new technology to provide energy.
The project, which was granted planning permission in August 2008, will consist of two four meter diameter Archimedes screw type turbines occupying two bays in the Romney Weir and will generate 300 kilowatts per hour at peak times, enough to power 600 households. It is estimated the turbines will reduce carbon dioxide emissions by 790,000 kilos per year.
This clean, green electricity will be used to power Windsor Castle.
Mann Power Consulting Ltd., the UK based Archimedean Screw specialists designed the equipment for the Romney Weir project. After various consultations it was decided that the most suitable turbine for the site was an Archimedean Screw.
The two 150kW Archimedean Screw turbines arrived on site in the early hours of Wednesday 7th September.
It is expected that the turbines will be installed and commissioned in the coming weeks.
The Archimedean Screw turbine provides a fish-friendly alternative to conventional turbines,
ideally suited to low-head (1m-10m) sites, and sites with fish protection issues.
Extensive fish passage tests have conclusively demonstrated that the large water chambers and slow rotation of the
Archimedean Screw allow fish of all sizes, and debris, safe passage through the turbine.
As a result, the Environment Agency has agreed that no screening is required. Literally thousands of fish passages have been monitored and recorded using underwater cameras at the intake, inside the chamber of the Screw itself and at the outflow to assess the effect of the Screw on salmonids (including smolts and kelts), brown trout and eels. The trials looked at fish passage across a broad spectrum of sizes and turbine speeds, possibly the most impressive of which was the safe passage of a kelt measuring 98cm in length and weighing 7.6kg. In addition, behavioural and migrational patterns across the species have been shown to be entirely unaffected by the turbine.
Dave Mann commissioned the fish passage studies instrumental in persuading the Environment Agency to accept the technology. Mann Power have a proven track record of successful installation throughout the UK and Ireland. One of the first challenges presented to Mann Power when Dave Mann set up the consultancy firm in 2003 was to find a hydropower solution for a community project in North Yorkshire, situated in a low head site within a Site of Special Scientific Interest with particular stipulations for the protection of an endangered fish species. The result of extensive research into possible solutions culminated in the introduction of the
Archimedean Screw turbine – already widely used in continental Europe
– for the first time into the UK, and Mann Power have been at the forefront of supplying this equipment for hydro generation projects since 2004. Mann Power now supplies this equipment throughout the UK and Ireland, as well as providing expert consultancy services.
Dave Mann, a member of the British Hydropower Association Council, has been instrumental in the design, installation and commissioning of all but a few of all
Archimedean screw power generation sites in the UK and Ireland
to date with over twenty schemes fully operational and a further forty or so at various stages of development. Mann Power have commissioned
several independent studies to verify the Archimedean Screw’s fish-friendly credentials and also its efficiency.
Mann Power is established within the national hydropower industry as a leader in the field of designing bespoke hydro-generation installations, specialising in low head and ‘difficult’ sites which previously may have been considered unsuitable for such applications.
Eco Evolution are appointed agents in Ireland of Mann Power Consulting Ltd (UK) who specialise in the
Archimedean Screw hydro turbine.
We also design modern water wheels for electricity generation.
All photographs courtesy of Mann Power Consulting Ltd.
